*Contact Eberbach for information on Cutting Mills.
The E3300 Mini Mill is an all steel Benchtop Cutting Mill featuring a 1.575-inch diameter sealed cutting chamber with two adjustable stationary blades and a rotating cutting head with four cutting edges that revolve at high speed to produce a shearing action that minimizes heat build-up (optional cutting chamber temp sensor is available). Samples introduced through the hopper are swept around by the rotor until they are cut to sufficient fineness to pass through the sieve.
The hard, steel cutting edges on the knives allow milling of a wider range of materials, including plastics, animal feed, bones, cables, cardboard, electronic scrap, feed pellets, foils, food, leather, material mixtures, non-ferrous metals, paper, pharmaceutical products, refuse-derived fuels, rubber, waste, wood and so much more. The E3300 is designed with a machine tool type of cartridge spindle, a small powerful motor with an operational speed of 1,200 RPMs with high torque. The chamber door comes standard with a door safety switch and the machine has legs to set on top of a benchtop or the legs can be removed and the machine can be bolted directly to a benchtop.
The E3300 is supplied with stainless steel hopper including cover, wooden plunger, one rotating cutting head, one set of stationary blades, three (3) stainless steel sieves (20, 40 & 60 mesh), one jar adapter, one 4oz collection jar, and cleaning brush. Please contact Eberbach regarding your comminution applications needs.
|Cutting Speed:||1200 rpm|
|Chamber Size:||1.575" Diameter|
|Sample Input Size:||0.6" Diameter|
|Sample Volume:||Volume Dependent on Sample - Contact us for details|
|Housing Material:||Powder Coated Steel or Stainless Steel|
|Sieve Material:||316 Stainless Steel|
|Electrical:||115V or 230V @ 50/60hz|
|Dimensions (without stand):||Length - 22 in | Width - 15 in | Height - 13 in|
